Raimondi Gladiator 130 Large Bridge Wet Saw (WSGLA130)

The Raimondi Gladiator 130 Large Bridge Wet Saw is designed for cutting granite, marble, porcelain, single-fired and double-fired tile, brick and cement. It supports straight, 45-degree bevel and plunge cuts.

The saw provides a maximum cutting length of 51-3/8 inches and accommodates blades from 9 to 10 inches in diameter. Its adjustable cutting depth handles material up to 3-1/8 inches thick in a single pass or 6 inches thick using a double pass.

Typical Applications

• Straight cutting
• 45-degree bevel or Jolly cutting
• Plunge cutting
• Wet cutting granite
• Wet cutting marble
• Wet cutting porcelain
• Cutting single-fired and double-fired tile
• Cutting brick and cement

Advantages

• Maximum cutting length of 51-3/8 inches
• Adjustable cutting depth
• Tilting motor assembly for bevel cuts from 0 to 45 degrees
• Re-adjustable square supports long-term cutting precision
• Floating blade guard remains in contact with the tile during operation
• Pivoting blade guard remains parallel with the tile to maintain cutting depth
• Belt-driven system optimizes motor torque and cutting capacity
• Cast and extruded aluminum framework
• Removable polypropylene water tank simplifies cleaning
• Heavy-duty water pump with two jet nozzles
• Telescopic legs include a safety device to help prevent collapsing
• Wheel kit supports easier transport

Specifications

• Brand: Raimondi
• Product line: Gladiator
• Model: Gladiator 130 Large Bridge Wet Saw
• Model number: WSGLA130
• Product type: Bridge wet saw
• Maximum cutting length: 51-3/8 inches
• Maximum cutting thickness, single pass: 3-1/8 inches or 80 mm
• Maximum cutting thickness, double pass: 6 inches or 150 mm
• Maximum blade diameter: 10 inches
• Minimum blade diameter: 9 inches
• Included blade diameter: 250 mm or 10 inches
• Bevel range: 0 to 45 degrees
• Cut types: Straight, bevel and plunge
• Drive system: Belt driven
• Motor-to-blade gear ratio: 1.4:1
• Drive belt type: Poly-V
• Framework: Cast and extruded aluminum
• Water tank material: Polypropylene
• Water tank capacity: 10 gallons
• Water delivery: Heavy-duty pump with two jet nozzles
• Jet nozzle mounting positions: Front or rear
• Motor housing: Cast aluminum
• Motor assembly pulleys: Four re-adjustable pulleys with double bearings; two are adjustable
• Rail construction: Extruded aluminum
• Leg design: Telescopic with anti-collapse safety device
• Recommended materials: Granite, marble, porcelain, single-fired and double-fired tile, brick and cement

Included Components

• 10-inch diamond blade for porcelain
• Wheel kit for transport
• Key kit
• Wrench
• Manual

Frequently Asked Questions

What is the maximum cutting length?

The maximum listed cutting length is 51-3/8 inches.

How thick can the saw cut?

It can cut material up to 3-1/8 inches or 80 mm thick in a single pass and up to 6 inches or 150 mm thick using a double pass.

Can the saw make bevel cuts?

Yes. The motor assembly tilts from 0 to 45 degrees for bevel or Jolly cuts.

What blade sizes can be used?

The saw accommodates blades from 9 to 10 inches in diameter.

What blade is included?

A 250 mm or 10-inch diamond blade for porcelain is included.

What materials can the saw cut?

The supplied product information identifies granite, marble, porcelain, single-fired and double-fired tile, brick and cement.

How large is the water tank?

The removable polypropylene water tank has a 10-gallon capacity.

Does the saw include a transport kit?

Yes. A wheel kit is included for easier transport.
