Noble ABS Drain with Square Nickel Strainer

The Noble ABS Drain features a square nickel strainer and a beveled flashing body and adapter designed for subfloor installation.

The strainer attaches to the drain body with four stainless-steel machine screws that thread into brass inserts. The drain body includes a membrane flange and a 2-inch Schedule 40 hub connection.

Typical Applications

• Shower pan drain installations
• Subfloor drain installations
• Connections to compatible DWV systems
• Installations requiring a square strainer

Advantages

• Square nickel strainer
• Beveled flashing body and adapter for subfloor installation
• Membrane flange incorporated into the drain body
• Four stainless-steel machine screws secure the strainer
• Brass threaded inserts
• 2-inch Schedule 40 hub connection

Specifications

• Brand: Noble
• Product type: Shower pan drain
• Drain material identified in title: ABS
• Strainer shape: Square
• Strainer finish: Nickel
• Strainer fasteners: Four stainless-steel machine screws
• Threaded inserts: Brass
• Hub connection: 2-inch Schedule 40
• Referenced standard: ASTM D2665

Product-Line Strainer Materials

The supplied product information lists the following available strainer styles within the product line:

• 18-gauge PVD-protected polished brass
• 18-gauge stainless steel
• 3/16-inch cast nickel and brass

This listing is identified as the version with a square nickel strainer.

Product Information Note: The product title identifies an ABS drain, but the supplied material list identifies the top housing, flashing collar and drain body as PVC. The supplied description also specifies a solvent-weld connection to PVC pipe. Confirm the drain-body material and compatible pipe type before ordering or installation.

Installation Information

• Install the beveled flashing body and adapter at the subfloor
• Connect the 2-inch Schedule 40 hub to the compatible DWV system
• Secure the strainer to the drain body with the four stainless-steel machine screws

Installation Note: Detailed membrane attachment procedures, solvent requirements and installation dimensions were not included in the supplied product information.

Frequently Asked Questions

What type of strainer does this drain include?

It includes a square nickel strainer.

What size pipe connection does the drain use?

It has a 2-inch Schedule 40 hub connection.

How does the strainer attach to the drain?

The strainer is secured with four stainless-steel machine screws that thread into brass inserts.

Is the drain body made from ABS or PVC?

The title identifies an ABS drain, while the supplied material list identifies PVC components. Confirm the exact drain-body material before ordering.

Does the drain body include a membrane flange?

Yes. The supplied product information states that the drain body includes a membrane flange.
