Makita GD0601 1/4-Inch Die Grinder

The Makita GD0601 1/4-Inch Die Grinder combines a powerful 3.5-amp motor with a slim-body design for grinding in a range of applications. The Makita-built industrial motor delivers 25,000 RPM, while the small-diameter barrel grip and conveniently positioned slide switch support comfortable handling and operation.

Front and rear air vents help the motor run cooler during continuous use and direct airflow away from the operator's face. Labyrinth construction and protective zig-zag varnish help shield the motor, bearings and armature coil from dust and debris.

The solid aluminum housing features a stepped-neck design for working in tight spaces and is protected by a removable rubber boot. An AC/DC switch allows the grinder to be used with alternative power sources.

Typical Applications

• Pipe fitting work
• Small-scale grinding
• Welding applications
• Plumbing work
• Shipbuilding
• Automotive work
• HVAC applications
• Grinding in tight spaces

Advantages

• Powerful 3.5-amp motor delivers 25,000 RPM
• Low operating noise of 73 dB(A)
• Small-diameter barrel grip for added comfort
• Directional airflow vents direct air away from the operator's face
• Round-shaped collet nut helps prevent scratches and damage to the workpiece
• Labyrinth construction helps protect the motor and bearings from debris
• Zig-zag varnish helps protect the armature coil from dust and debris
• AC/DC switch supports use with alternative power sources
• Slide switch with lock-on function
• Rubberized gear housing for increased operator comfort
• Stepped neck supports access in tight spaces
• Front and rear air vents help the motor run cooler
• Removable rubber boot protects the aluminum housing

Specifications

• Brand: Makita
• Model: GD0601
• Product type: Die grinder
• Collet size: 1/4 inch
• Motor: 3.5 amps
• Operating speed: 25,000 RPM
• Noise level: 73 dB(A)
• Switch type: Slide switch with lock-on
• Power compatibility: AC/DC
• Housing: Solid aluminum with removable rubber boot
• Motor protection: Labyrinth construction and zig-zag varnish
• Grip style: Small-diameter barrel grip
• Neck design: Stepped

Frequently Asked Questions

What is the operating speed of the Makita GD0601?

The 3.5-amp motor delivers 25,000 RPM.

What size collet does the grinder use?

The Makita GD0601 uses a 1/4-inch collet.

Does the grinder have a lock-on switch?

Yes. It includes a slide switch with a lock-on function.

Can the tool be used with AC and DC power?

Yes. The supplied product information identifies an AC/DC switch for use with alternative power sources.

How is the motor protected from dust and debris?

Labyrinth construction helps seal the motor and bearings, while zig-zag varnish helps protect the armature coil.

What applications is the GD0601 designed for?

It is designed for pipe fittings, small-scale grinding, welding, plumbing, shipbuilding, automotive and HVAC applications.
