Diamut T33 R3 FLX CNC Profile Wheel

High-speed Diamut CNC diamond profile tooling designed for precision stone edge profiling, increased feed rates, and efficient countertop production.

High-Speed CNC Profiling with the FLX Edge Design.

The Diamut T33 R3 FLX CNC Profile Wheel combines Diamut's HYS² high-speed tooling technology with the FLX profile design for professional stone fabrication. The FLX system is designed to round the top and bottom of slabs just shy of true 2 cm, 3 cm, and 4 cm profiles, providing fabricators with a controlled finished edge while supporting high-production CNC machining.

The FLX profile incorporates a 45-degree exit angle designed to bevel and polish the bottom side when the stone is thicker without digging into the material and leaving an unwanted lip. This makes the tooling particularly useful for shops processing varying slab thicknesses while requiring consistent edge geometry.

Diamut HYS² tooling is constructed with premium materials, high-performance bonds, and diamonds engineered for demanding CNC production. The system can reach feed rates up to 500 in/min on the second and third diamond positions, helping fabrication shops significantly reduce CNC cycle times while maintaining edge quality.

Typical Applications

• CNC countertop edge profiling
• FLX stone edge profiles
• 2 cm stone fabrication
• 3 cm stone fabrication
• 4 cm stone fabrication
• Top and bottom edge rounding
• High-speed CNC production
• Edge preparation before polishing

Advantages

• FLX design rounds both the top and bottom of the slab
• Designed for profiles just shy of true 2 cm, 3 cm, and 4 cm
• 45-degree exit angle helps finish thicker material without leaving a lip
• Designed for high-speed CNC stone fabrication
• Premium diamond construction
• High-performance diamond bond
• Precisely manufactured for consistent profiling
• Feed rates up to 500 in/min on second and third diamond positions
• Helps reduce CNC production cycle times
• Part of Diamut's HYS² CNC tooling system

Specifications

• Brand: Diamut
• Product: CNC Diamond Profile Wheel
• Profile: T33 R3 FLX
• Tool Type: CNC Profile Wheel
• Profile System: FLX
• Technology: Diamut HYS²
• FLX Thickness Options: Approximately 2 cm, 3 cm, and 4 cm
• Exit Angle: 45 Degrees
• Maximum Feed Rate: Up to 500 in/min on 2nd and 3rd Diamond Positions
• Application: Professional CNC Stone Edge Profiling

Diamut FLX Profile System

Diamut FLX sets are designed to round both the top and bottom edges of stone slabs while stopping just short of a true 2 cm, 3 cm, or 4 cm profile. The geometry provides a controlled edge that can be efficiently processed through the remaining tooling and polishing positions.

A 45-degree exit angle helps bevel and polish the lower portion of the edge when working with material that is slightly thicker than the nominal profile. This design helps prevent the tooling from digging into the stone and creating a lip along the bottom edge.

Diamut HYS² High-Speed CNC Tooling

Diamut's HYS² tooling was developed to increase CNC feed rates and improve fabrication shop productivity. Constructed using premium materials, high-performance bonds, and quality diamonds, the system is designed to maintain excellent edge quality while allowing CNC equipment to operate at substantially higher production speeds.

On the second and third diamond positions, Diamut tooling can reach speeds up to 500 inches per minute, compared with a promoted average feed rate of approximately 270 inches per minute. Diamut reports that its high-speed tooling can help fabrication shops reduce CNC run cycles by approximately 30–50%.

Why Choose the Diamut T33 R3 FLX?

The T33 R3 FLX combines high-speed HYS² diamond technology with a profile geometry developed specifically for efficient countertop edge production. Its ability to work with common slab thicknesses while controlling both the upper and lower edge makes it a versatile option for production fabrication.

For shops focused on reducing CNC cycle times while maintaining consistent edge geometry, the Diamut T33 R3 FLX provides a professional tooling solution designed around speed, precision, and repeatability.

BB Industries has you covered!

Frequently Asked Questions

What profile is this Diamut CNC wheel?

This wheel features the Diamut T33 R3 FLX profile for professional CNC stone edge fabrication.

What is the Diamut FLX profile system?

The FLX system is designed to round the top and bottom of slabs just shy of true 2 cm, 3 cm, and 4 cm profiles.

Why does the FLX profile have a 45-degree exit angle?

The 45-degree exit angle is designed to bevel and finish the bottom side of thicker stone without digging into the material and leaving a lip.

What is Diamut HYS² tooling?

Diamut HYS² is a high-performance CNC tooling system developed to increase feed rates and reduce production cycle times while maintaining finished edge quality.

How fast can Diamut HYS² tooling run?

The second and third diamond positions can reach feed rates up to 500 inches per minute.

Can Diamut HYS² tooling reduce CNC cycle times?

Yes. Diamut reports that its tooling can help fabrication shops reduce CNC run cycles by approximately 30–50%.
